Product Details:
Payment & Shipping Terms:
|
| Type: | 808nm Diode Laser | Feature: | Hair Removal,Skin Rejunation |
|---|---|---|---|
| Brand Name: | Heraeus | Lifetime: | 50,000,000 Flash |
| Output Mode: | Constant Spectral Output | ||
| High Light: | diode bar,laser diode stack |
||
Factory price Macro channel diode laser stack 760nm 808nm 1064nm / handle replacement Germany laser bar stack
Features
-AuSn hard-solder package, higher stability
-Higher power conversion efficiency
-Macro channel package, sealed house
-Higher reliability, longer life time
-Up to 50W QCW per Bar
-2.0mm pitch between Bars
-Up to 6-16 Bars in a single stack module
-Single or multi-wavelength 760nm, 808nm, 1064nm in a single stack module
-Active water cooling for optimized lifetime and power
-Low thermal resistance package
Applications
*Fast permanent Hair removal
*Skin rejuvenation
The macro channel laser stack consists of a heat sink and several light-emitting units that are packaged onto the surface of the heat sink. The heat-dissipating water circuit is inside the heat sink, and its water quality requirements are not high (no need to deionize water, but the water particles <100μm), the price is relatively low, and the cost performance is high.
a
| Model No | LaserTel |
| Application | Laser hair removal beauty machine and industry application |
| Operation Mode | CW |
| Power per submounts | 100W |
| Central wavelength at 25℃ | 808 ± 2.5nm |
| Maximum Operating Voltage | 2V |
| Fast Axis Divergence (FWHM) | No |
| Slow Axis Divergence (FWHM) | No |
| Expected lifetime | >10000 hours |
| Typical pitch per bar | 1.8mm |
| Cooling: | Distilled Water |
| Flow rate | 0.3L/min ±10% / bar |
| Water Temperature | 15-25 ℃ |
| Water Quality | Deionized 2-10 µs/cm, mixed bed ion exchanger,particle filter<25µm |
| cooling system | Do not use any material that combination with copper would form galvanic elements |
Micro-Channel Cooler Package (MCCP) is designed for high power CW diode bars up to 60W and 80W. The Micro-Channel Cooler (MCC or MC2) is a high efficiency heat-exchange heatsink. These MCCP package can provide up to >1KW CW output power from a single stack for directly heat treatment for industry, such as metal hardening, laser cladding, welding and etc. It is also widely used for hair removal applications.
Features:
Optical power 60W, 80W or 100W CW per bar
1~20 bars per stack
Vertical & horizontal stacks available
Typical 808+/-3nm, other wavelength (940nm, 976nm )available
Long life time > 10,000 hours
Support custom package design
